High Temperature Sintering Furnace

Name: High Temperature Sintering Furnace
Brand: UNITED ENTERPRISES
Price: 8000000.0 INR
Availability: InStock

Price 8000000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

High Temperature Sintering Furnace Specification

Rating
Up to 1800C continuous operation

Feature
Fast heating, programmable temperature controller, uniform temperature distribution

Condition
New

Type
High Temperature Sintering Furnace

Usage
Industrial thermal processing, laboratory sintering

Power
18 kW average (varies by model)

Voltage
415 V, 3 Phase

Size
Customizable as per requirements

Dimensions
Standard and custom sizes available

Weight
Approx. 400 - 1500 kg (varies by size)

Application
Ceramic, metallurgy, powder sintering, laboratory applications

Fuel Type
Electric

Capacity
30 to 500 liters (optional)

Temperature Uniformity
5C throughout the chamber

Display
Digital LED with temperature profile programming

Door Type
Front loading, insulated door

Control System
PID microprocessor based digital controller

Cooling Time
Less than 2 hours full cooling (model dependent)

Safety Features
Over-temperature protection, door interlock, emergency stop

Heating Element Material
Premium MoSi2 or SiC rods

Max Operating Temperature
1800C

Heating Rate
0-30C/min adjustable

Body Material
High-grade stainless steel with ceramic insulation

Chamber Type
Muffle or tube chamber options

About High Temperature Sintering Furnace

High Temperature Sintering Furnace manufactured by United Enterprises is engineered for sintering of advanced materials at temperatures well above conventional PM ranges typically up to 1800C and beyond, depending on configuration.

Brief Description:

Materials such as advanced ceramics, hard metals, refractory alloys, oxide and non-oxide ceramics need very high sintering temperatures with carefully controlled atmospheres. Our high temperature sintering furnaces use silicon carbide rods or MoSi2 (molybdenum disilicide) heating elements for stable, long-life service at extreme temperatures.

Both batch and continuous designs are offered, with vacuum, inert and reducing atmosphere variants. Multilayer high-quality fibre insulation, programmable temperature controllers (with up to 30 segment ramp-soak profiles), and modern safety devices are standard features.

Each furnace is custom built around the customers material, target temperature and atmosphere profile.

Characteristics:

Maximum temperature up to 1600C / 1700C / 1800C as required
MoSi2 / SiC heating elements
Multilayer ceramic fibre insulation
Programmable PID controller with 30-step ramp/soak
Vacuum / inert / reducing atmosphere options
Batch or continuous configurations
Imported heating elements for stable life
Customizable for any advanced material

About United Enterprises:

United Enterprises is among the leading high-temperature furnace manufacturers in India with over 25+ years of experience in advanced sintering and heat treatment equipment. We design, manufacture, supply, export and commission tailor-made high-temperature sintering furnaces across Asia and Europe. Our in-house engineering, turnkey delivery and CE / ISO compliant manufacturing serve advanced ceramics, hard metal and research industries.

FAQs:

Q: What heating element is best at 1700C+?

A: MoSi2 (molybdenum disilicide) is the typical choice at 1600C1800C. For lower temperatures, SiC rods or Kanthal A-1 wire may suffice.

Q: Which industries use high-temperature sintering?

A: Technical ceramics, hard metal tooling, refractory components, electronics substrates and research labs use this furnace.

Q: Do you offer rapid cooling?

A: Yes. Optional gas quench or rapid-cool systems can be added for shorter cycle times and finer microstructures.

Get It Now-your Last Chance to seize this Eminent High Temperature Sintering Furnace engineered for elite performance in industrial and laboratory environments. Featuring a monumental stainless steel body with ceramic insulation, this advanced furnace boasts a PID microprocessor controller, digital LED display, and precision heating up to 1800C. Clearance offering includes safety features like emergency stop and door interlock, customizable size, muffle or tube chambers, and atmosphere versatility-air, nitrogen, or argon. Invest in superior thermal processing-order now and elevate your operations!

Cutting-Edge Usage and Versatile Applications

This High Temperature Sintering Furnace stands out in elite industrial and research usage. Suited for ceramic, metallurgy, and powder sintering, it supports a broad spectrum of laboratory thermal processes. The advanced heating elements and uniform temperature distribution make it ideal for applications involving sensitive materials or controlled atmospheres, including air, nitrogen, or argon. Its robust construction ensures monumentally reliable operation across manufacturing labs, material research institutes, and process development facilities.

Main Domestic Market & Delivery Completion Value

Charge ahead in market value with this premium furnace, fit for leading domestic industries and laboratories across the region. Timely order completion is ensured, with tailored delivery times based on customization needs. Certified to meet rigorous industry standards, each furnace assures both performance and safety-fostering trust for every acquisition. Major certifications, rapid delivery, and dedicated support amplify its prominence in the elite thermal processing market, underlining its monumental value in your production workflow.

FAQ's of High Temperature Sintering Furnace:

Q: How does the furnace ensure precise temperature control and uniformity?

A: The furnace uses a PID microprocessor-based digital controller, enabling precise temperature adjustments and stable heating rates up to 30C per minute. It maintains temperature uniformity within 5C throughout the chamber, crucial for consistent sintering results.

Q: What applications can benefit from this high temperature sintering furnace?

A: It is ideal for ceramic processing, powder sintering, metallurgy, and laboratory applications involving high-temperature thermal treatments. Its versatile design supports diverse research, quality control, and small-scale production needs.

Q: When can I expect order completion and delivery after purchase?

A: Delivery times depend on your customization requirements. Standard models are available on short notice, while custom-built furnaces may have extended lead times to ensure all specifications are met. Our team will provide a detailed delivery schedule at order confirmation.

Q: Where can this furnace be installed?

A: The furnace is suitable for installation in industrial facilities, material research laboratories, universities, and quality assurance centers requiring advanced thermal processing for experimental or production use.

Q: What safety features are incorporated in the furnace design?

A: For user safety, the furnace comes equipped with an over-temperature protection system, door interlock mechanism, and an emergency stop function. These features prevent accidents and ensure safe operation at all times.
