Rotary Drum Furnace

Name: Rotary Drum Furnace
Brand: UNITED ENTERPRISES
Price: 2500000.0 INR
Availability: InStock

Price 2500000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Rotary Drum Furnace Specification

Rating
Industrial Grade

Feature
Fully Automatic, Uniform Heating, Energy Efficient, Low Maintenance

Condition
New

Type
Rotary Drum Furnace

Usage
Metal Melting / Heat Treatment

Power
Electric / Gas Fired

Voltage
380-440 V

Size
Customized as per requirement

Dimensions
Depends on Capacity (standard & custom sizes available)

Weight
3-20 Tons (as per model)

Application
Aluminium, Zinc, Copper, Lead Metal Melting, Reheating, Recycling

Fuel Type
Gas / Electric / Oil

Capacity
100 kg/hr to 10 T/hr

Heating Element
Electrical Heater / Gas Burner

Insulation Material
High Density Ceramic Wool / Fire Bricks

Material of Construction
Mild Steel / Stainless Steel

Temperature Range
Up to 1200C

Surface Treatment
Anti-Corrosive Paint Finish

Chamber Shape
Cylindrical Horizontal

Portability
Stationary / Custom mobile design

Max Load Per Batch
As per drum capacity

Exhaust System
Fume Extraction Provided

Control System
PLC Controlled / Semi-Automatic

Drum Rotation Speed
1-10 RPM (adjustable)

Rotary Drum Furnace Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
10-15 Days

About Rotary Drum Furnace

Rotary Drum Furnace manufactured by United Enterprises is a batch heat treatment system where the workload tumbles inside a slowly rotating drum, ensuring uniform exposure to the heat source ideal for small loose components.

Brief Description:

The rotary drum design is widely used for hardening, tempering and carbonitriding of small parts like fasteners, balls, rollers, chain links and similar items. The rotating drum keeps the parts in motion, ensuring uniform heat and atmosphere exposure across the entire load.

We supply rotary drum furnaces with both electric and recuperative gas-fired heating. Atmosphere control through our own Ammonia Cracker or Endo Gas Generator gives clean, oxide-free hardening.

Optional hydraulic tilting and an exit quench tank or conveyor ensure smooth, repeatable production cycles.

Characteristics:

Rotating drum for uniform component exposure
Suitable for hardening, tempering, carbonitriding
Maximum temperature up to 1100C
Cracked ammonia / endo gas atmosphere
Available in electric or gas-fired versions
Hydraulic tilting with quench tank (optional)
Variable speed drum drive
PLC and SCADA-based recipe control

About United Enterprises:

United Enterprises is an established Rotary Drum Furnace manufacturer in India with over 25+ years of industrial experience. We design, manufacture, supply, export and commission tailor-made rotary drum furnaces across Asia and Europe. Our turnkey delivery, in-house gas generator manufacturing and CE / ISO compliance make us a preferred partner for fastener, spring and small parts industries.

FAQs:

Q: Rotary drum vs rotary retort what is the difference?

A: They are conceptually similar. Rotary retort emphasises the sealed alloy retort with atmosphere; rotary drum can be a more general descriptor. Our engineers help select the right configuration.

Q: How small a part can it handle?

A: Even small balls and needles can be processed safely provided the drum lifters and atmosphere flow are tuned for the load.

Q: Can I use water quench instead of oil?

A: Yes, depending on the steel grade and target hardness. We supply both oil and water quench arrangements.

Introducing our unbeatable Rotary Drum Furnace, the kingly solution for industrial metal melting and heat treatment. Now available at a reduced price and marked as a masterful new release, this furnace boasts a robust mild steel or stainless steel build, adjustable 1-10 RPM drum rotation, and a PLC-controlled or semi-automatic system. Featuring high-density ceramic wool or fire brick insulation, it operates efficiently up to 1200C. Engineered for uniform heating, low maintenance, and energy efficiency, this masterpiece is ideal for aluminum, zinc, copper, or lead melting, reheating, or recycling. Experience unmatched reliability and customization - a price cut for industrial excellence!

Premium Features of Rotary Drum Furnace

The Rotary Drum Furnace features an anti-corrosive finish, uniform temperature distribution, and high-capacity loading options. Designed for maximum efficiency, it supports electric, gas, or oil fuel sources. Suitable for aluminum, zinc, copper, and lead processing, it is widely used by metal recycling plants, foundries, and metallurgical industries seeking energy efficiency and reduced operating costs. Its fully automatic operation and robust construction ensure superior performance in industrial-grade applications.

Rotary Drum Furnace Samples and Shipping Details

Sample Rotary Drum Furnaces are available upon request, with express shipping options to ensure timely delivery. Our packaging is engineered for safety and integrity, with each unit securely handed over at the designated FOB port. As part of our sample policy, customers can inspect the quality and build before committing to larger orders, making the purchasing process seamless and reliable for domestic or international clients.

FAQ's of Rotary Drum Furnace:

Q: How does the Rotary Drum Furnace ensure uniform heating during metal processing?

A: The Rotary Drum Furnace features an adjustable drum rotation speed and high-density insulation materials, ensuring consistent temperature distribution and uniform heating for all metal types processed inside the chamber.

Q: What materials can be melted or treated in the Rotary Drum Furnace?

A: This furnace is suitable for melting, reheating, and recycling aluminum, zinc, copper, and lead. Its industrial-grade construction makes it adaptable for various metalworking and recycling processes.

Q: When is it beneficial to choose a PLC-controlled system for this furnace?

A: Choosing a PLC-controlled system is beneficial for operations requiring precise temperature control, automation, and process consistency. This ensures better efficiency and reliability in large-scale or demanding industrial setups.

Q: Where can the Rotary Drum Furnace be installed and who commonly uses it?

A: These furnaces are typically installed in metal recycling plants, foundries, and metallurgical industries. They are widely preferred by manufacturers, exporters, and suppliers handling high-volume metal processing and heat treatment.

Q: What is the process for obtaining a sample Rotary Drum Furnace?

A: To obtain a sample, simply contact our sales team. The sample will be packaged securely and handed over at the designated FOB port, with express shipping available to expedite delivery and inspection.
