Price 800000.0 INR/ Unit

MOQ : 1 Unit

Gas Oven Specification

  • Control Mode
  • Digital PID Controller
  • Heating Capacity
  • up to 350C
  • Heating Method
  • Direct Gas Heating
  • Accuracy
  • 2C
  • Condition
  • New
  • Power Source
  • LPG/Natural Gas
  • Type
  • Industrial Gas Oven
  • Model
  • Industrial Gas Oven GO-1001
  • Internal Size
  • 1000 x 600 x 600 mm
  • External Size
  • 1350 x 900 x 1600 mm
  • Volume
  • 360 Litres
  • Air Flow
  • Uniform forced convection
  • Temperature Range
  • Ambient to 350C
  • Material
  • Mild Steel with Powder Coating
  • Dimension (L*W*H)
  • 1350 x 900 x 1600 mm
  • Power
  • 5 kW
  • Voltage
  • 220V / 50Hz
  • Surface Finish
  • Powder Coated
  • Insulation Thickness
  • 75 mm high-density ceramic wool
  • Mobility
  • Mounted on heavy-duty caster wheels
  • Chamber Construction
  • Double walled, rust-resistant
  • Door Type
  • Swing Door with gasket sealing
  • Ignition System
  • Automatic Electric Ignition
  • Exhaust Port
  • Adjustable exhaust damper
  • Safety Features
  • Over temperature protection & gas leak detector
  • Display
  • Digital temperature display
  • Suitable for
  • Baking, Curing, Drying, Preheating
  • Shelves
  • 2 adjustable shelves



About Gas Oven

Gas Oven manufactured by United Enterprises is an industrial gas-fired oven built for cost-effective drying, curing, baking and powder coating applications in steel, paint, food, textile and engineering industries.

Brief Description:

Gas ovens are widely chosen where natural gas, LPG or producer gas is available at reasonable cost. They reach operating temperature faster than electric ovens and offer lower running cost at higher capacity. Our gas ovens are built with multi-zone burner systems, hot-air recirculation and well-insulated walls for tight uniformity.

We offer gas ovens in batch (cabinet, walk-in) and continuous (conveyor, overhead conveyor) configurations. Direct and indirect fired designs are available depending on application.

Each oven is engineered for the customers product, throughput, fuel type and safety requirement.

Characteristics:

  • Industrial gas-fired oven
  • Typical temperature range up to 400C / 1200C depending on design
  • Batch or continuous configuration
  • Direct or indirect gas-fired heating
  • Multi-zone burner system with PLC control
  • Low-density high-quality insulation
  • Hot-air recirculation for uniform heating
  • Safety devices and operator-friendly design

About United Enterprises:

United Enterprises is a recognised Gas Oven manufacturer in India with over 25+ years of experience in industrial ovens. We design, manufacture, supply, export and commission tailor-made gas ovens across Asia and Europe. Our turnkey approach, in-house design and fabrication and CE / ISO compliance serve paint, powder-coating, food, textile and engineering industries.

FAQs:

Q: Gas oven vs electric oven?

A: Gas is generally cheaper to run at higher capacity and reaches higher temperatures faster. Electric is cleaner and easier to control.

Q: Direct or indirect fired?

A: Direct for general drying/curing; indirect for clean-product applications and food.

Q: Can I integrate it with my powder-coating line?

A: Yes. Conveyor and walk-in gas ovens are routinely integrated into powder-coating lines.



Advanced Safety and Precision Control

The GO-1001 industrial gas oven prioritizes safety and precision with its over-temperature protection and integrated gas leak detection. The digital PID controller enables accurate temperature maintenance, ensuring consistent results for sensitive processes. With a digital display, managing and monitoring internal conditions is effortless, making it ideal for complex and demanding applications.


Flexible and Efficient Design

Built with an adjustable exhaust damper, uniform forced convection, and two adjustable shelves, the oven delivers optimal airflow and heat distribution. The spacious 360-litre interior accommodates various batch sizes, while heavy-duty caster wheels make relocation straightforward. The double-walled, powder-coated mild steel construction resists rust, maximizing durability and longevity.

FAQ's of Gas Oven:


Q: How does the Gas Oven GO-1001 ensure safety during operation?

A: The oven features robust safety measures including over-temperature protection and a built-in gas leak detector. These features, combined with the gasket-sealed, double-walled chamber, provide a secure environment for continuous industrial use.

Q: What processes can be performed using this industrial gas oven?

A: This oven is suitable for a wide range of functions such as baking, curing, drying, and preheating, making it versatile for manufacturing, laboratory, or industrial settings.

Q: When should the adjustable exhaust damper be used?

A: The adjustable exhaust damper should be set during processes that require controlled removal of vapors or excess heat. This feature helps maintain optimal humidity and airflow inside the chamber.

Q: Where can the Gas Oven GO-1001 be installed?

A: Thanks to its heavy-duty caster wheels, the oven can be conveniently installed in laboratories, workshops, production lines, or any industrial facility requiring high-temperature processes. Proper ventilation and gas connections should be ensured.

Q: What benefits does the 75 mm high-density ceramic wool insulation offer?

A: The enhanced insulation minimizes heat loss, improves energy efficiency, and maintains safer external surface temperatures, resulting in more stable internal heating and reduced operating costs.

Q: How is uniform temperature achieved inside the oven?

A: The oven employs forced convection air flow and an automatic digital PID controller, ensuring uniform heat distribution and precise temperature control throughout the chamber.
