Pusher Type Sintering Furnace

Name: Pusher Type Sintering Furnace
Brand: UNITED ENTERPRISES
Price: 6000000.0 INR
Availability: InStock

Price 6000000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Pusher Type Sintering Furnace Specification

Feature
Uniform Heating, Energy Efficient, PLC Controlled

Rating
High Temperature, Industrial Grade

Condition
New

Type
Pusher Type Sintering Furnace

Usage
Sintering of Metal Powder Components and Ceramics

Power
Electric/ Gas

Voltage
380V/ 415V, Three Phase

Size
Customizable, dependent on production requirement

Dimensions
As per clients specification

Weight
Approximately 3-15 Tons (as per size/ model)

Application
Powder Metallurgy, Ferrite, Ceramics, Electronics

Fuel Type
Electricity or Gas

Capacity
Variable; Typically 50-500 kg/batch

Max Temperature
Up to 1300C

Process Cycle Time
Adjustable

Cooling Section
Integrated Water-Cooled Section

Surface Finish
Anti-Corrosive Coated

Furnace Atmosphere
Hydrogen, Nitrogen, or Argon

Material of Construction
High-quality Insulating Bricks and Stainless Steel

Insulation Material
High Alumina/ Ceramic Fibre

Control System
PLC/SCADA based Automatic Control

Heating Zone
Single/ Multiple Zones

Safety Features
Over Temperature Protection, Emergency Stop

Door Type
Automatic Pusher Mechanism

Loading System
Continuous Pusher Tray System

Pusher Type Sintering Furnace Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5-10 Days

About Pusher Type Sintering Furnace

Pusher Type Sintering Furnace manufactured by United Enterprises is a continuous high-output sintering furnace where trays of powder compacts are advanced through the furnace by a programmable pusher mechanism.

Brief Description:

The pusher-type design provides a stable, predictable production cycle and is preferred where heavy trays and large compacts are involved. The line typically includes pre-heating, sintering, slow-cool and rapid-cool zones, with atmosphere control via our in-house Ammonia Cracker or Endo Gas Generator.

Available in both electric and recuperative gas-fired heating, the furnace is built for long campaign life with high-density refractory hearth tiles and quality alloy components. Multi-zone PLC and SCADA control deliver consistent metallurgical results.

Each unit is custom engineered for the customers product range, daily output and atmosphere requirement.

Characteristics:

Continuous pusher operation for steady production
Maximum temperature up to 1080C
Cracked ammonia / endo gas atmosphere
Available in electric or gas-fired heating
Multi-zone PLC and SCADA temperature control
Heavy-duty alloy hearth tiles for long life
Optional slow-cool / rapid-cool sections
Customizable for any production scale

About United Enterprises:

United Enterprises is among the recognised Pusher Type Sintering Furnace manufacturers in India with over 25+ years of experience. We design, manufacture, supply, export and commission tailor-made pusher sintering furnaces across Asia and Europe. Our turnkey approach, in-house gas generator manufacturing and CE / ISO compliance make us a preferred partner for the powder metallurgy and hardware industries.

FAQs:

Q: How is sintering uniformity ensured?

A: Through controlled tray spacing, multi-zone heating and stable atmosphere managed in real time through PLC and SCADA.

Q: Can the furnace be expanded later?

A: Yes. Additional zones (pre-heat, soak, cooling) can be added when the customer scales production.

Q: What about belt vs pusher choice?

A: Pusher is preferred for heavier tray loads and larger compacts; belt is more suitable for small, light components.

Spotlight your manufacturing prowess with the splendiferous Pusher Type Sintering Furnace, meticulously engineered for the sintering of metal powder components and ceramics. This exceptional furnace boasts a customizable capacity (50-500 kg/batch), advanced PLC/SCADA automatic controls, and a continuous pusher tray system ensuring uniform heating and energy efficiency. Constructed with high-quality stainless steel and insulated with high alumina materials, it supports atmospheres of hydrogen, nitrogen, or argon, delivering reliable results. Enjoy competitive pricing and an exclusive, industrial-grade solution that promises durable, anti-corrosive finishes and robust safety features.

Exceptional Features and Versatile Applications

The Pusher Type Sintering Furnace stands out due to its integrated water-cooled section, automatic pusher mechanism, and anti-corrosive finish. Designed for the splendiferous sintering of metal powders, ferrites, ceramics, and electronic components, it ensures superior material quality and consistent results. Its sturdy stainless steel construction with high alumina/ceramic fibre insulation supports demanding industrial environments, while automatic PLC controls guarantee process precision tailored to varied production needs.

Supply Ability, Payment Flexibility, and Logistics

As a leading exporter, manufacturer, and supplier, we offer competitive logistics and timely delivery options to suit your production requirements. Transportation is meticulously coordinated to ensure safe arrival of your furnace. Flexible payment terms help ease procurement, while our sample policy provides customers with insight into exceptional quality before bulk orders. Each shipment is delivered securely, accommodating client specifications and supporting global distribution for seamless industrial integration.

FAQ's of Pusher Type Sintering Furnace:

Q: How does the automatic pusher mechanism enhance the sintering process?

A: The automatic pusher mechanism streamlines continuous material loading and unloading, resulting in increased efficiency, uniform heat exposure, and reduced manual handling, all while supporting high-volume production cycles.

Q: What is the process cycle time, and can it be adjusted as per requirements?

A: Yes, the process cycle time of the pusher type sintering furnace is fully adjustable, enabling users to optimize the sintering duration for different materials or batch sizes to achieve exceptional output consistency.

Q: Where can the Pusher Type Sintering Furnace be used most effectively?

A: This furnace excels in industries such as powder metallurgy, ferrite manufacturing, ceramics production, and electronics, ensuring splendid results for sintering diverse metal powders and ceramic components.

Q: What safety features are integrated into the furnace design?

A: Key safety features include over temperature protection, an emergency stop mechanism, and PLC/SCADA oversight, ensuring operator safety and protecting equipment during high-temperature industrial operations.

Q: What benefits does the high alumina/ceramic fibre insulation provide?

A: The use of high alumina or ceramic fibre insulation delivers outstanding thermal stability, energy efficiency, and resistance to high temperatures, which contributes to prolonged furnace lifespan and uniform heating across the batch.
