Billet Re-Heating Furnace

Name: Billet Re-Heating Furnace
Brand: UNITED ENTERPRISES
Price: 4500000.0 INR
Availability: InStock

Price 4500000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Billet Re-Heating Furnace Specification

Rating
High Thermal Efficiency

Feature
Uniform heating, sturdy construction, energy-efficient design

Condition
New

Type
Continuous Pusher Type

Usage
Industrial billet heating

Power
Optional (Hydraulic / Electric Pushers)

Voltage
415 V / 380 V

Size
Customizable as per plant requirement

Dimensions
As per design specifications

Weight
Varies with capacity and design

Application
Steel mills and rolling mills

Fuel Type
Furnace Oil / Natural Gas / Producer Gas / LDO

Capacity
10 TPH - 50 TPH (Tons Per Hour)

Door Type
Hydraulically Operated (if required)

Heat Recovery System
Optional Recuperator for improved efficiency

Operating Pressure
Atmospheric

Billet Size Range
100 mm x 100 mm to 200 mm x 200 mm and custom

Automation Grade
Semi-Automatic / Automatic

Control System
PLC/SCADA Based Automated Controls

Chimney Height
As per environmental norms

Material of Construction
Mild Steel refractory lining

Refractory Lining Thickness
115 mm to 350 mm as required

Max Temperature
Up to 1300C

Firing System
Top/Burner, Flat/Burner, or Side/Burner as per design

About Billet Re-Heating Furnace

Billet Re-Heating Furnace manufactured by United Enterprises is a continuous reheating furnace specifically designed to bring steel billets to uniform rolling or forging temperature with high thermal efficiency.

Brief Description:

For bar and section rolling mills, consistent billet temperature directly affects rolling quality and mill productivity. Our billet reheating furnaces use pusher or walking beam designs with multi-zone heating and recuperative burners to deliver tight temperature uniformity and low fuel consumption.

Each unit is engineered around the customers billet size, weight, throughput and target discharge temperature. Robust mechanical design, high-grade refractories and modern combustion control make the furnace dependable for long-term mill operations.

PLC and SCADA based combustion management ensures consistent product quality across shifts.

Characteristics:

Continuous billet reheating up to 1200C
Pusher or walking beam configuration
Recuperative burners with air pre-heating
Multi-zone temperature and combustion control
High-quality refractory for long campaign life
Tight discharge temperature uniformity
PLC and SCADA-based monitoring
Customizable for billet size and throughput

About United Enterprises:

United Enterprises is a recognised Billet Re-Heating Furnace manufacturer in India with over 25+ years of experience in rolling mill reheating systems. We design, manufacture, supply, export and commission tailor-made billet reheating furnaces across Asia and Europe. With turnkey delivery, in-house design and fabrication and CE / ISO compliant manufacturing, we are a trusted partner for re-rolling mills and structural steel producers.

FAQs:

Q: How is fuel consumption controlled?

A: Through recuperative burners, air pre-heating, refractory insulation and SCADA-based combustion control.

Q: Can I use multiple billet sizes?

A: Yes. The skid and pusher layout is designed to accommodate the customers billet size range.

Q: Do you handle full erection and commissioning?

A: Yes. We provide complete turnkey delivery engineering, supply, erection, commissioning, training and AMC.

Experience the unrivaled performance of our Billet Re-Heating Furnace, a must-have for every steel and rolling mill aiming for precision and efficiency. Crafted with venerable mild steel refractory lining and commanding construction, this furnace delivers uniform heating up to 1300C. Its semi-automatic or automatic automation grade ensures seamless operation, while optional PLC/SCADA control offers superior monitoring. Ending soon: Don't miss out-order today and benefit from industrial-grade reliability, customizable sizes, high thermal efficiency, and cutting-edge heat recovery!

Competitive Edge & Machine Features

Our Billet Re-Heating Furnace stands out for its sturdy construction, advanced automation, and unparalleled energy efficiency. With customizable billet size options, high thermal efficiency, and integrated PLC/SCADA controls, it ensures optimal operation in demanding industrial environments. Extra features include a hydraulically operated door, optional recuperator for heat recovery, and flexibility in fuel choice-making it the preferred choice for manufacturers seeking both performance and adaptability.

Certifications & Delivery Information

Our furnaces meet rigorous industry certification standards, ensuring safety and performance. We primarily serve the main domestic market with prompt goods transport tailored to your requirements. Delivery time is estimated based on size and customization, with detailed charges provided upfront. Rest assured, you'll receive fully certified, ready-to-operate equipment delivered as per agreed timelines, ensuring a seamless installation and integration process.

FAQ's of Billet Re-Heating Furnace:

Q: How does the automation grade impact furnace operation?

A: The Billet Re-Heating Furnace is available in both semi-automatic and automatic versions, allowing operators to select the level of automation suitable for their workflow. Automated controls enhance precision, reduce manual intervention, and contribute to consistent heating performance.

Q: What materials are used in the refractory lining and why?

A: The furnace uses mild steel with refractory lining ranging from 115 mm to 350 mm thickness. This combination provides durability, excellent heat retention, and extended equipment lifespan even under high-temperature industrial usage.

Q: When is the optional heat recovery system recommended?

A: The optional recuperator heat recovery system is recommended when you aim to boost energy efficiency and reduce operational costs. It recycles waste heat, making it highly beneficial for plants prioritizing sustainability and optimized fuel consumption.

Q: Where can this furnace be used?

A: This furnace is engineered for steel mills and rolling mills. Its robust construction, customization options, and various fuel compatibilities make it suitable for a wide range of industrial billet heating applications.

Q: What are the main benefits of hydraulically operated doors?

A: Hydraulically operated doors enhance operational safety and convenience. They provide smooth, reliable opening and closing, reduce labor requirements, and ensure optimal sealing during the heating process, contributing to better energy retention and process efficiency.
