Cabinet Oven

Name: Cabinet Oven
Brand: UNITED ENTERPRISES
Price: 550000.0 INR
Availability: InStock

Price 550000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Cabinet Oven Specification

Accuracy
2C

Heating Method
Forced Air Circulation

Condition
New

Power Source
Electric

Heating Capacity
12 kW

Control Mode
Digital PID Controller

Type
Cabinet Oven

Model
CO-1267

Internal Size
1000mm x 600mm x 1000mm

External Size
1200mm x 800mm x 1500mm

Volume
600 L

Air Flow
Horizontal or Vertical (Adjustable)

Temperature Range
Ambient to 300C

Material
Stainless Steel (Inner), Mild Steel (Outer)

Dimension (L*W*H)
1200mm x 800mm x 1500mm

Power
3 Phase, 50 Hz

Voltage
415V

Surface Finish
Powder Coated

Weight
Approx. 350 kg

Viewing Window
Tempered glass observation window

Timer
Programmable digital timer

Number of Trays
4 trays supplied

Application
Industrial drying, curing, baking, aging

Mobility
Mounted on caster wheels

Overheat Protection
Yes, with safety cut-off

Door Type
Double-walled insulated

Insulation Thickness
100 mm mineral wool

Noise Level
<70 dB

About Cabinet Oven

Cabinet Oven manufactured by United Enterprises is a compact, easy-to-use industrial oven ideal for drying, curing and low-temperature heat treatment of small to medium-sized batches.

Brief Description:

Cabinet ovens are the workhorses of small production shops, R&D labs and pilot plants. The compact design fits easily into limited floor space, while multi-zone hot-air recirculation ensures uniform heating across all shelves and product positions.

We offer cabinet ovens in electric, gas-fired and steam-heated versions with digital or PLC-based temperature control. Stainless-steel inner construction is available for clean-room and food-grade applications.

Each cabinet oven is engineered for the customers product, cycle time and temperature range.

Characteristics:

Compact cabinet design for small batches
Maximum temperature typically up to 450C
Available in electric, gas-fired and steam-heated versions
Hot-air recirculation for uniformity
Stainless steel inner option for clean-room use
Digital or PLC temperature control
Low-density insulation for energy efficiency
Customizable as per user requirement

About United Enterprises:

United Enterprises is a trusted Cabinet Oven manufacturer in India with over 25+ years of experience in industrial ovens and drying systems. We design, manufacture, supply, export and commission tailor-made cabinet ovens across Asia and Europe. Our turnkey approach, in-house design and fabrication and CE / ISO compliance serve pharma, food, paint, electronics and small engineering industries.

FAQs:

Q: How small can a cabinet oven be?

A: Compact bench-top units to medium-sized double-door cabinets sized as per your products and batch volume.

Q: Stainless steel or mild steel interior?

A: Stainless steel is preferred for pharma, food and clean-room applications; mild steel is more economical for general drying/curing.

Q: Do you supply with shelves and trays?

A: Yes. Adjustable shelves and trays designed for your products are included as part of the supply.

Exceptional Thermal Efficiency and Safety

The CO-1267 cabinet oven is built for rigorous use and features 100 mm mineral wool insulation along with double-walled doors, drastically reducing energy loss and enhancing operator safety. The overheat protection system, combined with a safety cut-off, delivers worry-free operation even during continuous processes. A tempered glass viewing window allows for safe monitoring without disturbing internal conditions.

Advanced Controls and Flexible Operation

Fitted with a digital PID controller and programmable digital timer, this oven achieves precise temperature accuracy within 2C, supporting customizable process cycles. Adjustable horizontal or vertical airflow ensures even and consistent heat distribution, making it suitable for varying batch sizes and product types. Mobility is facilitated by caster wheels, making installation or repositioning straightforward for dynamic production layouts.

FAQ's of Cabinet Oven:

Q: How does the forced air circulation in the Cabinet Oven CO-1267 enhance uniform heating?

A: The forced air circulation system can be set to either horizontal or vertical airflow, ensuring that heat is evenly distributed throughout the oven chamber. This results in consistent drying, curing, or baking across all trays, eliminating cold spots and enhancing product quality for industrial applications.

Q: What safety features does the CO-1267 model offer for industrial use?

A: This cabinet oven is equipped with advanced safety features, including overheat protection with an automatic safety cut-off. The thick mineral wool insulation and double-walled insulated doors further ensure minimal heat transfer to the outer surfaces, reducing burn risk and improving operational safety.

Q: When should I use the programmable digital timer, and what are its benefits?

A: You should use the programmable digital timer to precisely control process durations such as drying, curing, or aging cycles. This feature helps automate operations, increases process repeatability, and reduces operator oversight, leading to enhanced workflow efficiency.

Q: Where can the Cabinet Oven CO-1267 be used most effectively?

A: This oven is ideally suited for industrial environments such as manufacturing plants, laboratories, and facilities involved in material testing, baking, curing, or aging where controlled heating and consistent results are mandatory.

Q: What process controls are available and how accurate are they?

A: The oven comes with a digital PID controller, offering fine-tuned temperature regulation with a high degree of accuracy (within 2C). Operators can program specific temperature profiles and process durations to match unique industrial requirements.

Q: How do the caster wheels benefit the operation of this cabinet oven?

A: Mounted on caster wheels, the oven is easy to relocate or position within a workspace, enabling flexible integration into evolving production lines or laboratory setups without the need for heavy lifting equipment.

Q: What are the main benefits of the CO-1267's construction materials and insulation?

A: The stainless steel inner chamber resists corrosion and makes cleaning straightforward, while the mild steel exterior with powder-coated finish offers structural strength. The 100 mm mineral wool insulation minimizes energy loss, resulting in lower operating costs and a safer exterior surface during high-temperature operations.
