Indirect Fired Oven

Name: Indirect Fired Oven
Brand: UNITED ENTERPRISES
Price: 800000.0 INR
Availability: InStock

Price 800000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Indirect Fired Oven Specification

Power Source
Diesel/Gas (Indirect Fired)

Heating Capacity
120 kW

Heating Method
Indirect Fired

Control Mode
Digital Temperature Controller

Condition
New

Accuracy
2C

Type
Batch Type Indirect Fired Oven

Model
IFO-2800

Internal Size
2650 mm x 1100 mm x 1600 mm

External Size
2800 mm x 1250 mm x 1800 mm

Volume
4.6 m3

Air Flow
Balanced Forced Air Circulation

Temperature Range
Ambient to 350C

Material
Mild Steel with High-Temperature Resistant Coating

Dimension (L*W*H)
2800 mm x 1250 mm x 1800 mm

Power
12 kW (for electrical components)

Voltage
415 V, 3 Phase

Surface Finish
Powder Coated

Safety Features
Overheat Protection, Flame Failure Alarm, Emergency Stop

Timer
Programmable Digital Timer (0-999 min)

Application
Curing, Baking, Drying for Industrial Use

Insulation Thickness
100 mm Mineral Wool

Burner Type
Industrial Grade Modulating Burner

Door Type
Heavy Duty Swing Door with Silicon Gasket

Optional Accessories
Trolley, Heat Resistant Racks, Data Logger

Weight
Approx. 950 kg

Exhaust System
Integrated Flue Gas Exhaust with Damper

Heat Exchanger Material
Stainless Steel

About Indirect Fired Oven

Indirect Fired Oven manufactured by United Enterprises is a clean-heating industrial oven where combustion products are kept separate from the product through a heat exchanger ideal for food, pharma and clean-product applications.

Brief Description:

Indirect fired ovens use gas burners that heat a heat-exchanger; only clean, recirculated air enters the product chamber. This makes the design ideal for applications where contamination from combustion products is unacceptable food, pharma, electronics and clean industrial coatings.

We supply indirect fired ovens in cabinet, walk-in and conveyor configurations. Multi-zone heating, hot-air recirculation and PLC-based control deliver uniform, repeatable cycles.

Each oven is engineered around the customers product, throughput and safety standards.

Characteristics:

Clean indirect-fired design with heat exchanger
Typical temperature range up to 350C
Suitable for food, pharma, electronics and clean coatings
Multi-zone burner system with PLC control
Hot-air recirculation for uniform heating
Low-density high-quality insulation
Cabinet, walk-in or conveyor configurations
Safety devices and operator-friendly design

About United Enterprises:

United Enterprises is a recognised Indirect Fired Oven manufacturer in India with over 25+ years of experience in industrial ovens. We design, manufacture, supply, export and commission tailor-made indirect fired ovens across Asia and Europe. Our turnkey approach, in-house design and fabrication and CE / ISO compliance serve food, pharma, electronics and specialty coating industries.

FAQs:

Q: When should I prefer indirect fired over direct fired?

A: Where combustion products may contaminate the product food, pharma, electronics and certain clean coatings.

Q: What is the efficiency difference vs direct fired?

A: Indirect fired ovens have a small additional thermal loss through the heat exchanger; for clean-product applications this trade-off is justified.

Q: Do you offer hygienic design?

A: Yes. Stainless-steel construction, smooth interior, hygiene-friendly seals and CIP ports can be added for pharma and food.

Industrial Performance with Robust Construction

Constructed from mild steel with a high-temperature powder-coated finish, the IFO-2800 provides durability and resistance in challenging industrial settings. The 100 mm mineral wool insulation ensures minimal heat loss, leading to energy efficiency and consistent oven performance. Balanced forced air circulation ensures uniform heat distribution for optimal batch processing.

Precision Control and Enhanced Safety

Equipped with a digital temperature controller and a programmable timer (0-999 min), this oven offers high accuracy (2C) and scheduling flexibility. Integrated safety features-including overheat protection, a flame failure alarm, and an emergency stop-ensure secure operation. The digital control panel allows easy adjustments to temperature and process timing.

Versatile Applications and Optional Accessories

Designed for curing, drying, or baking, the IFO-2800 adapts to various industries. Optional accessories like trolleys, heat-resistant racks, and a data logger expand operational capabilities, streamlining product handling and tracking. The oven's spacious internal chamber (4.6 m3) accommodates large batches and supports efficient throughput.

FAQ's of Indirect Fired Oven:

Q: How does the indirect fired heating method of the IFO-2800 oven improve operational safety and product quality?

A: Indirect fired heating keeps combustion gases separated from the process chamber, ensuring that only clean air circulates around your products. This method reduces contamination risks and enhances uniformity, contributing to higher-quality curing, baking, or drying results, while also making the process safer for operators.

Q: What are the main industrial applications for the IFO-2800 oven?

A: The IFO-2800 is designed for curing, baking, and drying processes in industrial environments. It is suitable for materials and products that require precise temperature control up to 350C, making it ideal for manufacturing, research, and specialized production applications.

Q: When should I use the programmable digital timer, and how does it benefit my process?

A: Use the programmable digital timer to precisely set the duration of each heat cycle, ranging from 0 to 999 minutes. This feature allows for consistent batch processing, reducing the risk of over- or under-processing and improving operational efficiency.

Q: Where can the oven be installed, considering its size and power requirements?

A: With external dimensions of 2800 mm x 1250 mm x 1800 mm and a weight of approximately 950 kg, the oven requires a spacious, well-ventilated industrial area. It operates on 415V 3-phase power, so installation near suitable electric and diesel/gas supply connections is ideal.

Q: What is the function of the integrated flue gas exhaust and damper system?

A: The flue gas exhaust with a damper safely removes combustion gases from the oven, maintaining a clean process environment and optimizing heat retention. The damper helps regulate the exhaust flow, contributing to efficient operation and stable process temperatures.

Q: How does the balanced forced air circulation system contribute to uniform heating within the oven?

A: The balanced forced air circulation evenly distributes heated air throughout the oven chamber, ensuring consistent temperature profiles. This uniformity helps avoid hotspots and guarantees reliable, repeatable results across all areas of the batch.
