Patenting Furnace for Steel Wire

Name: Patenting Furnace for Steel Wire
Brand: UNITED ENTERPRISES
Price: 5000000.0 INR
Availability: InStock

Price 5000000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Patenting Furnace for Steel Wire Specification

Feature
Energy Efficient, Uniform Heating, Low Maintenance

Rating
Industrial Grade

Condition
New

Type
Continuous Patenting Furnace

Usage
Steel Wire Heat Treatment

Power
Electric/ Gas based (as per requirement)

Voltage
220V / 380V / 415V (customizable)

Size
Customizable as per requirement

Dimensions
As per client specification

Weight
Depends on model and size

Application
Wire Annealing and Patenting

Fuel Type
Electricity, LPG, Natural Gas, Oil

Capacity
Up to 5 tons/hour

Insulation
High-grade ceramic insulation

Max Wire Diameter
Up to 15 mm

Surface Finish
Corrosion Resistant Coating

Material of Construction
Stainless Steel / Mild Steel

Automation Grade
Semi-Automatic / Fully Automatic

Cooling System
Water or Air Quenched

Temperature Range
Up to 1100C

Max Wire Speed
Up to 25 m/min

Control Panel
Digital PLC based

Heating Method
Direct/Indirect

Patenting Furnace for Steel Wire Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
5-10 Days

About Patenting Furnace for Steel Wire

Patenting Furnace for Steel Wire manufactured by United Enterprises is a continuous heat treatment system that produces fine-grained patenting sorbite in high-carbon steel wire, enabling further cold drawing to high tensile strength levels.

Brief Description:

Patenting is essential for producing high tensile drawn wire used in springs, ropes, prestressing strands and tyre cord. The wire is heated to around 950C in the furnace and then rapidly cooled in a molten medium (typically lead, salt or fluidised bed) at around 550C.

Our patenting furnaces are built for continuous high-volume operation, with automatic temperature regulation within 1C, low-shrinkage refractory lining and special hearth design to minimise wire-hearth contact. Both electric and gas-fired versions are available.

Each line is tailored to the customers wire diameter range, throughput and downstream drawing plan.

Characteristics:

Continuous patenting for high-carbon steel wire
Heating up to 950C, controlled rapid cooling
Available in electric or gas-fired versions
Automatic temperature regulation 1C
Low-shrinkage refractory lining
Special hearth design for minimum wire contact
Suitable for spring, rope, tyre cord and prestressing wire
PLC and SCADA-based control

About United Enterprises:

United Enterprises is a recognised Patenting Furnace for Steel Wire manufacturer in India with over 25+ years of experience in high-tensile wire heat treatment lines. We design, manufacture, supply, export and commission tailor-made patenting furnaces across Asia and Europe. With turnkey delivery, in-house engineering and CE / ISO compliance, we serve spring, rope, prestressing and tyre cord industries.

FAQs:

Q: What is the typical wire diameter range?

A: From fine specialty wires under 1 mm to thicker wires above 6 mm the line can be customized accordingly.

Q: Lead, salt or fluidised bed?

A: Lead is traditional, salt is widely used where lead is restricted, and fluidised bed is the most modern alternative. We supply all three.

Q: Do you supply downstream drawing equipment?

A: We focus on heat treatment lines, but we can also help integrate drawing and surface treatment equipment from approved partners.

The Patenting Furnace for Steel Wire is a popular, hot-selling solution among preeminent steel wire manufacturers. Crafted with enlightened engineering, it boasts blue-ribbon quality using stainless steel or mild steel construction. Suitable for both semi-automatic and fully automatic operations, this continuous furnace features a high-precision digital PLC control panel and versatile power options (electric, gas, oil, LPG, natural gas). It achieves uniform heating up to 1100C, accommodates wire up to 15 mm diameter and 25 m/min speed, and is highly customizable in dimension, voltage, and capacity, making it an ideal choice for industrial-grade steel wire heat treatment. Excellent energy efficiency, robust insulation, and a corrosion-resistant coating ensure low maintenance and long service life.

Engineered for Advanced Steel Wire Patenting

This furnace is designed for continuous use in steel wire annealing and patenting. Built with corrosion-resistant stainless steel or mild steel, it handles wire diameters up to 15 mm and speeds up to 25 m/min, making it perfect for high-volume production. The furnace's high-grade ceramic insulation ensures excellent thermal efficiency, while its customizable size and automation options suit diverse industrial requirements. Its direct or indirect heating adapts to specific material and process demands.

Reliable Dispatching and Order Fulfillment Commitment

We ensure swift dispatching post order completion, prioritizing timely deliveries and industry-best lead times at the lowest price. Every patenting furnace is securely packaged to guarantee safe arrival and undamaged installation. Comprehensive documentation accompanies each order. Our streamlined process-from customization to delivery-ensures clients receive fully tailored solutions meeting their specific needs and schedule, with every detail managed for convenience.

FAQ's of Patenting Furnace for Steel Wire:

Q: How does the Patenting Furnace for Steel Wire improve production efficiency?

A: With its energy-efficient design, uniform heating, and customizable automation grades, this furnace enhances throughput and minimizes downtime, increasing overall production efficiency.

Q: What materials are used in the construction of the furnace?

A: The furnace is constructed using either premium stainless steel or mild steel, both treated with a corrosion-resistant coating for extended durability.

Q: When can I expect delivery after placing an order?

A: Delivery timelines are confirmed at the time of order completion, factoring in customization requirements. We strive to dispatch each unit promptly and provide detailed tracking information.

Q: Where can the Patenting Furnace be used?

A: Ideal for wire manufacturers and processing plants, this furnace is suited to any industrial facility specializing in steel wire annealing and patenting processes.

Q: What are the main benefits of the digital PLC control panel?

A: The PLC control panel ensures precise, consistent temperature regulation, easy operation, and adaptable settings for various wire types and production speeds.
